DIY FPV mini drone RED HAWK Nighthawk 250 frame kit DX2205 KV2300 + BL20A ESC 2-4S OPTO + SP racing F3 with OSD + 700TVL WEBCAM

$138.97

Buy product

Compare

Description



DIY FPV mini drone RED HAWK Nighthawk 250 frame kit

DX2205 KV2300 + BL20A ESC 2-4S OPTO + SP racing F3 with OSD + 700TVL WEBCAM

N250B



RED HAWK mini BL20A ESC 2-4S OPTO support oneshot125:

  • Nighthawk 250 pure carbon fiber frame(4*2*2mm) * 1 set
  • SP racing F3 ACRO built-in OSD *1
  • Original LB RED HAWK DX2205 2300KV motor *4 (2cw/2ccw)
  • Original LB RED HAWK BL20A ESC opto ( 2-4S) * 4
  • TS5823 200MW Video transmission transmitter with antenna * 1
  • 700TVL CCD HD camera PAL 2.8mm lens * 1
  • 6045 bullnose propeller 2 blades * 8 pairs(ramdom colors)
  • PCB board 5V 12V with BEC * 1
  • RGB 7 color LED light  * 4
  • 2.0 banana connector * 12 male and 12 female
  • 10cm Heat shrinkable tube * 2
  • XT60 male plug with cable * 1
  • Nylon cable ties * 8

******************************************************************************************************************

N250ALittle bee mini BL20A pro ESC:

  • Nighthawk 250 pure carbon fiber frame(4*2*2mm) * 1 set
  • SP racing F3 ACRO built-in OSD *1
  • Original LB RED HAWK DX2205 2300KV motor *4 (2cw/2ccw)
  • Original LB RED HAWK BL20A ESC opto ( 2-4S) * 4
  • TS5823 200MW Video transmission transmitter with antenna * 1
  • 700TVL CCD HD camera PAL 2.8mm lens * 1
  • 6045 bullnose propeller 2 blades * 8 pairs(ramdom colors)
  • PCB board 5V 12V with BEC * 1
  • RGB 7 color LED light  * 4
  • 2.0 banana connector * 12 male and 12 female
  • 10cm Heat shrinkable tube * 2
  • XT60 male plug with cable * 1
  • Nylon cable ties * 8
Package list :
RED HAWK Nighthawk 250 quadcopter frame kit * 1 setE
RED HAWK BL20A ESC OPTO support oneshot125 :
Voltage: 6-16.8V (2-4S lithium polymer)
Output Current: 18-22A
Maximum current: 30A less than 5S
BEC: None
Signal Refresh Rate: 20-600Hz
Firmware: BLHeli stable version 14.2 firmware, contact customer service for the latest firmware (can brush Simonk)
Bootloader: ATMEL BLheli Bootloader (support naze32 brush writing process)
Weight: 7 g (with wires)
Size: 23 * 12 * 4.5 mm
Power cable: 20AWG silicone wire 10CM
Motor wire: 20AWG silicone wire 10CM
Signal line: 2P 17CM

little bee BL20A pro ESCSpecifications
  •     Size: 24.5 x 12.5 x 3mm
  •     Weight: 4g without wires,7g with wires
  •     Continuous current: 20 Amps
  •     Burst current (10s): 30 Amps
  •     Input voltage: 2-4s LiPo
  •     Firmware: BLHeli 14
  •     Bootloader: BLHeli Bootloader
  •     Mosfet: N-Channel
  •     BEC: None, OPTO
  •     USB Programmable: Yes
  •     PCB board: 4-layer blind pole board, 3 oz copper

mini camera:

  • Product Name: 4140 673 HD 700TVL FPV camera
  • Mini camera Size: 32mm * 32mm, weight: 13 g
  • Total pixels: PAL: 1020H × 596V NTSC: 1020H × 508V
  • Effective Pixels: PAL: 976H × 582V NTSC: 976H × 494V
  • Signal System: PAL / NTSC (PAL system default, choose the NTSC system)
  • Resolution (horizontal center): 700TVL
  • Digital Noise Reduction: 2D Digital Noise Reduction (2DNR) 0-15 16 support levels can be adjusted
  • WDR: digital wide dynamic (adaptive gradation reproduction)
  • OSD menu: Support
  • Audio: For audio, please contact customer service modified Microphones
  • Minimum illumination: 0.001LUX / F1.2
  • SNR: ≥48dB
  • Video Output: 1.0Vp-p / 75Ω
  • AGC: 0.25 / 0.50 / 0.75 / 1.00 four levels can be adjusted to up to 55dB
  • White Balance: On / Off selectable
  • Backlight compensation: high brightness backlight compensation (HLC) / Backlight Compensation
  • Exposure mode: Electronic exposure
  • Electronic Shutter: 1/50 (1/60) – 100000 seconds
  • Gamma Correction: 0.45 / 1.0
  • Synchronization: Internal synchronization
  • Lens: 2.8mm
  • Working voltage: DC12V (wide voltage 7-18V can be found to work)
  • Operating Current: 45mA (low power)
  • Working temperature: -20°C–60°C
  • Humidity: 0% to 98%
