DIY FPV mini drone QAV-R SP F3 power kit RED HAWK DX2205 + Red hawk 20A ESC / little bee 20A pro ESC + TS5823 + 700TVL camera

$117.00

Buy product

Compare

Description



DIY FPV mini drone SP F3 power kit

RED HAWK DX2205 + Red hawk 20A ESC / little bee 20A pro ESC + TS5823 + 700TVL camera

this power kit is specially adapted for QAV-R quadcopter frame

item 1:D2

  • SP RACING F3 6DOF *1
  • Original LB RED HAWK DX2205 2300KV motor *4 (2cw/2ccw)
  • Original LB RED HAWK mini BL20A ESC opto ( 2-4S) * 4
  • TS5823 200MW Video transmission transmitter with antenna * 1
  • CMOS 700TVL HD camera PAL 2.8mm lens 25mm*25mm * 1(with accs package)
  • 5045BN V2 3 blades Prop * 2 pairs(random colors)
  • 5045 bullnose propeller 2 blades * 2 pairs(ramdom colors)
  • 4045 bullnose propeller 2 blades * 2 pairs(ramdom colors)
  • PCB board 5V 12V with BEC * 1
  • RGB 7 color LED light  * 4
  • 2.0 banana connector * 12 male and 12 female
  • 10cm Heat shrinkable tube * 2
  • XT60 male plug with cable * 1
  • Nylon cable ties * 8

*********************************************************************************************************

item 2:

D1A

  • SP RACING F3 6DOF with OSD *1
  • Original LB RED HAWK DX2205 2300KV motor *4 (2cw/2ccw)
  • Original LB RED HAWK mini BL20A ESC opto ( 2-4S) * 4
  • TS5823 200MW Video transmission transmitter with antenna * 1
  • CMOS 700TVL HD camera PAL 2.8mm lens 25mm*25mm * 1(with accs package)
  • 5045BN V2 3 blades Prop * 2 pairs(random colors)
  • 5045 bullnose propeller 2 blades * 2 pairs(ramdom colors)
  • 4045 bullnose propeller 2 blades * 2 pairs(ramdom colors)
  • PCB board 5V 12V with BEC * 1
  • RGB 7 color LED light  * 4
  • 2.0 banana connector * 12 male and 12 female
  • 10cm Heat shrinkable tube * 2
  • XT60 male plug with cable * 1
  • Nylon cable ties * 8

****************************************************************************************

item 3:D3

  • SP racing F3 6DOF *1
  • Original LB red hawk DX2205 2300KV motor *4 (2cw/2ccw)
  • Little bee mini BL20A pro ESC opto ( 2-4S ) * 4
  • TS5823 200MW Video transmission transmitter with antenna * 1
  • 700TVL CMOS PAL HD camera 2.8mm lens 25mm*25mm * 1(with accs package)
  • 5045BN V2 3 blades Prop * 2 pairs(random colors)
  • 5045 bullnose propeller 2 blades * 2 pairs(ramdom colors)
  • 4045 bullnose propeller 2 blades * 2 pairs(ramdom colors)
  • PCB board 5V 12V with BEC, LED switch * 1
  • RGB 7 color LED light  * 4
  • 2.0 banana connector * 12 male and 12 female
  • 10cm Heat shrinkable tube * 2
  • XT60 male plug with cable * 1
  • Nylon cable ties * 8
****************************************************************************************************************************

item 4:

D3A

  • SP racing F3 6DOF with OSD *1
  • Original LB red hawk DX2205 2300KV motor *4 (2cw/2ccw)
  • Little bee mini BL20A pro ESC opto ( 2-4S ) * 4
  • TS5823 200MW Video transmission transmitter with antenna * 1
  • 700TVL CMOS PAL HD camera 2.8mm lens 25mm*25mm * 1(with accs package)
  • 5045BN V2 3 blades Prop * 2 pairs(random colors)
  • 5045 bullnose propeller 2 blades * 2 pairs(ramdom colors)
  • 4045 bullnose propeller 2 blades * 2 pairs(ramdom colors)
  • PCB board 5V 12V with BEC, LED switch * 1
  • RGB 7 color LED light  * 4
  • 2.0 banana connector * 12 male and 12 female
  • 10cm Heat shrinkable tube * 2
  • XT60 male plug with cable * 1
  • Nylon cable ties * 8

Package list :
DIY FPV mini drone QAV-R SP F3 power kit  * 1 set
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Red hawk mini BL20A ESC:
Voltage: 6-16.8V (2-4S lithium polymer)
Output Current: 18-22A
Maximum current: 30A less than 5S
BEC: No
Signal Refresh Rate: 20-600Hz
Firmware: BLHeli stable version 14.2 firmware, contact customer service for the latest firmware (can brush Simonk)
Bootloader: ATMEL BLheli Bootloader (support naze32 brush writing process)
Weight: 7 g (with wires)
Size: 23 * 12 * 4.5 mm
Power cable: 20AWG silicone wire 10CM
Motor wire: 20AWG silicone wire 10CM
Signal line: 2P 17CM

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

little bee BL20A pro ESC Specifications:

  •     Size: 24.5 x 12.5 x 3mm
  •     Weight: 4g without wires,7g with wires
  •     Continuous current: 20 Amps
  •     Burst current (10s): 30 Amps
  •     Input voltage: 2-4s LiPo
  •     Firmware: BLHeli 14
  •     Bootloader: BLHeli Bootloader
  •     Mosfet: N-Channel
  •     BEC: None, OPTO
  •     USB Programmable: Yes
  •     PCB board: 4-layer blind pole board, 3 oz copper

mini camera:

  • Size: 25mm * 25mm, weight: 9.5 g
  • Total pixels: PAL: 1020H × 596V (61 million pixels)
  • Effective Pixels: PAL: 976H × 582V (57 million pixels)
  • Signal System: PAL / NTSC (PAL system by default, you can choose NTSC)
  • Resolution (horizontal center): 700TVL
  • Video Output: 1.0Vp-p / 75Ω
  • AGC: 0.25 / 0.50 / 0.75 / 1.00 four levels can be adjusted to up to 55dB
  • White Balance: On / Off selectable
  • Exposure mode: Electronic exposure
  • Electronic Shutter: 1/50 (1/60) – 100000 seconds
  • Gamma Correction: 0.45 / 1.0
  • Synchronization: Internal synchronization
  • Lens: standard 2.8mm lens
  • Working voltage: DC12V (wide voltage, can be found 7.5-13V work)
  • Operating Current: 70mA (low power)
  • Working temperature: -20 °C –60 °C Humidity: 0% to 98%



***********************************************************************
